CONTROL PANEL
86037780 EXTRACTOR 02/15/08
5
REF
PART
NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86007200 72162 1 SWITCH, DPDT 3-POSITION ROCKER
2 86002010 14942 2 BOOT, 3/8 CIRCUIT BREAKER
3 86173140 70945 2 SCR, KA40X16, PT OVAL, WN1412, PL
4 86217410 270152 1 COVER, CONTROLS TOP
5A 86230140 14622 1 BREAKER, 1.5A CIRCUIT 115V ONLY
5B 86001780 14308 1 BREAKER, 0.8A CIRCUIT 230V ONLY
6A 86291460 - 1 BREAKER, 11A VDE CIRCUIT 115V ONLY
6B 86198130 141047 1 BREAKER, 6A VDE CIRCUIT 230V ONLY
7 86223420 67622 1 RELAY, 10A 230VAC SPDT 230V ONLY
8 86302680 - 1 EMI FILTER MAIN 230V ONLY
9 86292300 - 2 SCR, M4X20 SBHCS, BLK EDP
10 86173350 87515 2 WASHER, M5, FLAT, ISO7089, SS
11 86216300 140956 2 BUMPER, CONSOLE
SEE WIRING DIAGRAM FOR WIRE CONNECTIONS.
