Windsor MPRO 10080390 User Manual

HANDLE
86037780 EXTRACTOR 08/15/08
5
-
10
REF
PART
NO.
PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86012660 - 3 SCR, KA40X25, PT OHCS, WN1452,PL
2 86218570 38342 1 HANDLE, GRIP BOTTOM
3 86225910 38343 1 WELDMENT, HANDLE TUBE
4 86218560 38341 1 HANDLE, GRIP TOP
5 86225140 72204 1 SWITCH, MICRO
6 86224650 730392 1 SPRING, LEVER
7 86216470 140922 1 BUTTON, SPRAY HANDLE
8 86219460 41553 1 HUB, SPLINE HANDLE
9 86216440 140934 1 BUSHING, SHAFT HANDLE
10 86219660 48113 1 KEY, HANDLE CAM, 4X24MM
11 86221790 51548 1 LEVER CAM HANDLE
12 86217360 270138 1 COVER, TUBE HUB LEFT
13 86277600 70882 3 SCR, M4 X 20, PHMS, ISO7045, SET
14 86008650 80604 1 COTTER, 1/4” RING
15 86222600 66887 1 PIN, CLEVIS 5MM
16 86224150 730405 1 SHAFT, HANDLE CAM
17 86222340 57512 1 NUT, M12, LOCK. ISO 7040, SST
18 86259430 87485 1 WASHER, M12 FLAT
19 86173220 70954 4 SCR, M6X12 PHCS, 12.5MM HD, SS
20 86224930 730012 1 STRAIN RELIEF, 14/3 STRAIGHT
21 86224460 730406 1 SPACER, SHAFT HANDLE
22 86224140 730404 1 SHAFT, HANDLE
23 86217380 270144 1 COVER, TUBE HUB RIGHT
24 86010640 87016 2 WASHER, #10 LOCK EXT STAR
25 86270800 57014 1 NUT, 10-32 HEX SS
26 86217350 270135 1 COVER, CONTROLS, BOTTOM
27 86172870 70898 4 SCR, M4X14 PHMS, DIN7985 SST
28 86215520 140921 1 BRACKET, HANDLE AXLE
29 86233170 20054 1 CLAMP, 3/8 NYLON UL/CSA
30A 86217140 23732 1 CORD ASM, 14X3 SJTX25’ 115V ONLY
30B 86288380 23706 1 CORD ASM, AB EURO 230V ONLY
30C 86217030 23710 1 CORD ASM, AUST AB 230V ONLY
31 86173030 70917 3 SCR, M4 X 6, PHMS, ISO7045, PL
32 86005640 57030 1 NUT, 10-32 HEX NYLOCK
33 86218230 35376 1 GASKET, CONTROL BOX RIGHT
34 86218220 35375 1 GASKET, CONTROL BOX LEFT
35 86013730 - 1 SHEILD, MICROSWITCH
36 86173320 87510 3 WASHER, FLAT M4 DIN125 SST
37 86006770 70323 2 SCR, 10-32 X 1/4 PH PLTD
38 86288680 87230 4 WASHER, M5 RIVET BACKUP
39 OPEN - - -
40 86296620 -
AS
REQ’D
WASHER, 0.2X19.8X25.0MM PLTD
1008039000001
41 86292550 - 1 BUSHING, HANDLE LOCK 1008039000001
42 86296610 - 1 LEVER, CAM HANDLE 1008039000001
43 86296600 - 1 COVER, HUB TUBE LEFT 1008039000001
44 86292560 - 1 SHAFT, HANDLE LOCK 1008039000001
45 86266630 - 1 PIN, DOWEL 5 X 25MM, PLTD 1008039000001
46 86297150 - 1 HANDLE, GRIP TOP 1008039000126
47 86297160 - 1 HANDLE, GRIP BOTTOM 1008039000126
48 86298790 - 1 WELDMENT, HANDLE TUBE 1008039000126
49 86173140 70945 4 SCR, KA40 X 16, PT OHCS, WN1452PL 1008039000126
50 86266080 76040 1 TERM, 18G .25 FEMALE COUPLER
