Windsor Titan 708 - Page 12

T720TP TANK ASSEMBLY
No. Part Num. Description Qty.
1. S82048 Tank – 400 1
2. S81026 Screw, M5 x 30 4
3. S83883 Plastic Washer 4
4. S83028 Hook, Latch 1
5. S82970 Release Swivel 2
6. S82969 Release Knob 2
7. S81847G6 Clamp 2
8. S81300 Rivet 4
9. S82652AG6 Hose Adapter 1
10. S82593 Deflector, Tank 1
11. S82846 Gasket 1
No. Part Num. Description Qty.
12. S82586AG6 Retainer, Tank Adapter 1
13. S81050 Screw, M5 x 35 4
14. S82594BL Push Button, Two-Piece, Blue 1
15. T9007 Label, Titan 1
T720TP CART
11
No. Part Num. Description Qty.
1. S82185 Base 1
2. S80976 Plastic Pad 2
3. S80478 Nut, M10 2
4. S81012 Washer, M10 2
5. S80479 Wheel, Caster 2
6. S82896 Wheel 2
7. S82922 Washer 2
8. S83607 Plastic Retainer 2
9. S82972 Axle Cap 2
10. S86250 Hand Grip 2
