1786369590 Titan Vacuum
Vacuum Motor Assembly - T716 / T720TP
REF PART NO. ALT NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1A 8.616-284.0 S81122 CORD, 120 VOLT
1B 8.616-283.0 S80117 CORD, 230 VOLT
2 8.616-407.0 S80138 1 STRAIN RELIEF
3 8.616-421.0 S80139 1 TERMINAL CLIP
4 8.616-386.0 S81006 2 SCREW, 5 X 20
5 8.616-389.0 S81054 4 SCREW, 5 X 50
6 8.616-329.0 S86097AUG6 1 HANDLE, GRAY
7 8.616-392.0 S81979 2 SCREW, 5 X 25
8 8.616-385.0 S81005 2 SCREW, 5 X 14
9 8.616-423.0 S80490 1 TERMINAL BLOCK
10 8.616-288.0 S86070AUB.LAB 1 COVER, BLUE
11 8.616-415.0 S80326 1 SWITCH, ON/OFF
12 8.616-312.0 S83937 1 FILTER
13 8.616-318.0 S81502 1 GASKET
14 8.616-274.0 S83383 2 CAP
15 8.616-286.0 S82957AUG6 1 COVER, GRAY
16 - S82627 9 SCREW, 5 X 40
17 8.616-349.0 S82937AUG6 1 MOTOR BASE, GRAY
18 - S81004 1 SCREW, 3 X 19
19 8.616-422.0 S80450 1 TERMINAL BLOCK
20 8.616-321.0 S83969 1 GASKET
21 8.616-378.0 S80310 1 RING
22 8.616-320.0 S83901 3 L-GASKET
23A 8.616-347.0 S81120S 1 MOTOR, 120 VOLT
23B 8.616-351.0 S83891S 1 MOTOR, 230 VOLT
24 8.616-350.0 S83451 2 MOTOR SEAL
25 - S82454 3 FILTER
26 8.616-310.0 S83456 3 FILTER
27 8.616-264.0 S83519 1 BASE PLUG
28 8.616-263.0 S83108GG6 1 BASE
29 8.616-341.0 T9008 1 LABEL, WINDSOR LOGO
