PARTS LIST / VS14 / 120V
POS
PRODUCT
CODE
PRV NO. DESCRIPTION DESIGNATION
100 86140590 2635WI COVER ASSEMBLY VS14 CARTER SUPERIEUR MOTEUR
101 86140530 2542 COVER, VSE BRUSH STRIP COUVERCLE DE BARTETTE
102 86345590 2592bl CHASSIS VSE-1 GRY BUMPER 14 CHASSIS, CPL
103 86138860 2522HG BUMPER PARE CHOC
104 86137910 2539DG
XE
106 86141700 2528OR FOOT PEDAL PEDALE DE PIED
107 86146570 2010 WHEEL RETURN SPRING RESSORT D’AXE
108 86146590 2012DG WHEEL AND END CLIP ROUE ET CLIPS DE ROUE
109 86140000 2014ER CLAMP CONNECTING ROD (AXLE) BRIDE DE SERRAGE
110 86143820 2622DG PILE ADJUSTMENT KNOB BOUTON DE REGLAGE
111 86145270 4019 SPRING RESSORT
112 86137880 2524
RTICULATION, CPL
115 86146740 2541UL WIRE/SWIVEL NECK 3-WIRE CABLE ELECTRIQUE
116 86145240 2546 SPRING, VSE LEAF RESSORT PLAT
117 86143050 2534 LEVER, VSE SWITCH LEVIER CONTROLE
118 86145820 2530HG SWIVEL NECK COVER COUVERCLE D’ARTICULATION
119 86145420 2538 SUPPORT, VSE SWIVEL SUPPORT D’EMBOUT
120 86138430 2030ER BRUSH ASM, 14” ROULEAU DE BROSSE
121 86002440 2046 BRUSH STRIP 14” BARRETTE DE BROSSE
122 86138110 2091 BEARING BLOCK, VSM/VSE LH BLOC ROULEMENT GAUCHE
123 86144430 2458 PULLEY, VSE BRUSH ROLLER POULIE DE BROSSE
124 86138100 2047 BEARING BLOCK, VSM/VSE RH BLOC DE ROULEMENT DROIT
125 86138460 2241UL BRUSH MOTOR DRIVE, 115V U70G32 MOTEUR DE BROSSE 120V
126 86139380 05095S CARBON BRUSH SET 120V LEVIER DE SUPPORT
127 86144420 2025 PULLEY-MOTOR POULIE MOTEUR
128 86147010 4024 DRIVE BELT COURROIE
129 86140290 2572ER CONTROL PC BOARD VSE1/3 CONTROL ELECTRIQUE 120V
130 86145440 2652HG SUPPORT LEVER LEVIER DE SUPPORT
131 86345580 2651 SPRING, VSE RETURN RESSORT
132 86147030 0102ER SCR M3,9 X 13 MM DIN 7981 VIS F M3,9 X 13 MM DIN 7981
133 86147040 0103ER SCR, M3,9 X 16 MM DIN 7981 10PK VIS C 3,9 X 16 DIN 7981
134 86144880 0174ER SCREW, BRIDGE SR VIS, BRIDGE SR
135 86147070 0111ER SCR M5 X 30 MM DIN 7985A NP VIS M5 X 30 MM DIN 7985A NP
136 86145190 0149ER SPACER WASHER RONDELLE
