WineEnthusiast N'FINITY WINE RACK KIT User Manual

N'FINITY WINE RACK KIT - 4 COLUMN CURVED CORNER WITH DISPLAY
PARTS & HARDWARE
A1
Left ladder
4 pcs
CODE DESCRIPTION QTY
SKETCH DRAWING
Note:
Phillips Head screwdriver, electric screwdriver or electric drill required for assembly. Electric
screwdriver is the preferred choice for ease of assembbly. When using electric drill or electric
screwdriver, do not overtighten screws to minimize the risk of wood splitting.
A2
Right ladder
4 pcs
B
C
D
E1
F2
G
Top And Bottom Front Bar
Front Trim
1-
1
4
" #8 screw
3
4
" #6 screw
Metal Front Support
Bottom Back Bar
2 pcs
1 pcs
3 pcs
8 pcs
56 pcs
3 pcs
H
Metal Back Support
4 pcs
E2
1-
1
2
" #8 screw
16 pcs
F1
1
2
" #6 screw
12 pcs
