N'FINITY WINE RACK KIT - 4 COLUMN CURVED CORNER WITH DISPLAY
ASSEMBLY INSTRUCTIONS
4
Step 4. Install the metal back support (H) to back side of left ladder (A1) and right ladder (A2) with 32 screws (F1). See
detail -T for clarification.
