N'FINITY WINE RACK KIT - 4 COLUMN CURVED CORNER WITH DISPLAY
ASSEMBLY INSTRUCTIONS
3
A1
A2
Detail -R
Step 3. Attach the metal front support (G) to front side of left ladder (A1) and right ladder (A2) with 24 screws (F1). See
detail -R for clarification. Next, attach front trim (D) to metal front support with 12 screws (F2). See detail -S for clarification.
D
D
D
G
G
G
F1
F1
F1
A2
A2
A2
A1
A1
A1
Detail -S
Detail -S
F2
F2
F2
F2
F2
