Winkhaus AV2 / E Manual 3
General
information
Fabrication
Procedures
Installation
Procedures
Operating
Instructions
Routine
Maintenance
Troubleshooting
Guides
Sash
Routing Details
Frame
Routing Details
1
2
3
4
5
6
7
Table of Contents
1 Fabrication Procedures Page 4
1.1 Sash & Frame Preparation Page 4
1.2 Hardware Installation Page 4
1.3 Fabrication Final checks and adjustments Page 5
2 Installation Procedures Page 6
2.1 Installation Set Up Page 6
2.2 Glazing Page 6
2.3 General Door Set up Page 7
2.4 Installation checks and adjustments Page 7
3 Operating Instructions Page 8
4 Routine Maintenance Page 9
5 Troubleshooting Guides Page 10
5.1 AV2 Locking System (automatic/manual) Page 10
5.2 AV2 E Locking System (Electromechanical) Page 11
6 Frame Routing Details Page 12
6.1 F24 AV2 Keeps: Full Length Page 12
6.2 F24 AV2 Keeps: Single Pocket Page 13
6.3 F24 AV2 Keeps: One piece full length rounded end Page 14
7 Sash Routing Details Page 15
7.1 AV2 & AV2 E 20mm Face Plate Page 15
7.2 AV2 & AV2 E 20mm Rounded End Face Plate Page 16
7.3 AV2 & AV2 E 16mm Face Plate Page 17
