6-5
SECTION 6
APPLIANCES & EQUIPMENT
6 - APPLIANCES &
EQUIPMENT
Shut-Down of Ice Maker
To turn the ice maker off, simply raise the
shutoff arm (wire).
Winterizing the Ice Maker
When winterizing, make sure the water line
is completely drained by following this proce-
dure.
1. Drain coach water lines. See Sect. 10.
2. Unscrew the water supply line from the bot-
tom of the water inlet valve and drain any
water left in the line. This connection is
located in the refrigerator service compart-
ment on the outside of the coach. (See
Refrigerator Service Access Compartment.)
3. Let the ice maker run through a cycle, then
raise the shut-off arm.
4. Be sure water has drained from ice maker
supply line, then reconnect to inlet valve.
Start-Up (Removing from Storage)
1. Close all drain valves.
2. Turn the water supply on.
3. Be sure the ice bin is in place and the auto-
matic shutoff arm is down.
4. Let the refrigerator cool down to ice making
temperature. Remember, this can take up to
24 hours.
5. Let the ice maker cycle and dump the first
batch of ice.
REFRIGERATOR SERVICE
ACCESS COMPARTMENT
(Exterior)
The exterior refrigerator service compartment
allows access to the rear of the refrigerator for in-
spection, maintenance and service.
To Ope n:
1. Use a screwdriver or coin to turn the latch
knobs to the vertical position as shown.
2. Remove the door from the opening.
To Close:
1. Replace the door into the opening.
2. Push the latch knobs in while turning to the
horizontal position as shown.
Ice Maker Water Supply Connection
Turn latches open with coin
Refrigerator Access Door Latches
