SECTION 7 –
PLUMBING
7-12
24VR Waterlines: • Two (2) valves beneath shower. Access through
removable panel on lower front of shower cabinet.
• Two (2) valves beneath the bed mattress. Lift mattress to
access.
Water Tank: One (1) valve beneath the bed mattress. Lift mattress to
expose access hole.
Water Heater: Drain plug on outside of coach, behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve:
Beneath bed. Lift mattress along the front to expose access
hole.
Winterization
(Antifreeze) Valve:
Located beneath bed. Lift mattress along front to expose
access hole.
29TR Waterlines: Two (2) valves in galley. Remove bottom panel.
Water Tank: One (1) valve beneath the bed. Lift mattress to expose
access hole.
Water Heater: Drain plug on outside of coach, behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve:
Beneath galley sink. Access through removable panel on
lower front of cabinet.
Winterization
(Antifreeze) Valve:
Beneath the bed. Lift mattress to expose access hole.
31CR Waterlines: Three (3) valves in galley. Remove bottom drawer.
Water Tank: One (1) valve beneath the bed. Lift foot of mattress to
expose access hole.
Water Heater: Drain plug on outside of coach, behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve:
Under galley sink. Remove bottom drawer to access.
Winterization
(Antifreeze) Valve:
Beneath the bed. Lift foot of mattress to expose access hole.
31JR Waterlines: Two (2) valves beneath lavatory sink. Access through
removable panel.
Water Tank: One (1) valve beneath the bed. Lift mattress to expose
access hole.
Water Heater: Drain plug on outside of coach behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve:
Beneath galley sink. Remove panel to access.
Winterization
(Antifreeze) Valve:
Located beneath bed. Lift mattress to expose access hole.
