Winnebago Chalet - Specifications and Capacities

1-5
SECTION 1 –
INTRODUCTION
SPECIFICATIONS AND CAPACITIES
29TR 31CR 31JR
Standard
Ford
®
E350
Chassis
Optional
Ford
®
E450
Chassis
Ford
®
E450
Chassis
Ford
®
E450
Chassis
Ford
®
E450
Chassis
Feature Number 16C 16Y 16Y 16Y 16Y
Length 25' 25' 30' 5" 31' 8" 32' 1"
Exterior Height
1
10' 11" 10' 11" 10' 11" 10' 11" 10' 11"
Exterior Width
6
8' 5" 8' 5" 8' 5" 8' 5" 8' 5"
Exterior Storage w/ Slideout
2
NA NA 74.6 cu. ft. 86.8 cu. ft. 34.8 cu. ft.
Exterior Storage w/o Slideout
2
38.7 cu. ft. 38.7 cu. ft. 72.2 cu. ft. NA NA
Awning Length 11' 6" 11' 6" 14' 16' 10' 6"
Interior Height 6' 8" 6' 8"
6" 10" Front
6' 4" Rear
6" 10" Front
6' 4" Rear
6' 8"
Interior Width 8' 8' 8' 8' 8'
Freshwater Capacity
3
36 gal. 36 gal. 36 gal. 36 gal. 36 gal.
Water Heater Capacity 6 gal. 6 gal. 6 gal. 6 gal. 6 gal.
Optional Water Heater Capacity 6 gal. 6 gal. 6 gal. 6 gal. 6 gal.
Holding Tank Capacity - Black
3
39 gal. 39 gal. 41 gal. 41 gal. 30 gal.
Holding Tank Capacity - Gray
3
29 gal. 29 gal. 41 gal. 41 gal. 39 gal.
Propane Capacity
4
18 gal. 18 gal. 18 gal. 18 gal. 18 gal.
Fuel Capacity 55 gal. 55 gal. 55 gal. 55 gal. 55 gal.
GCWR
5
18,500 lbs. 20,000 lbs. 20,000 lbs. 20,000 lbs. 20,000 lbs.
GVWR 11,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs.
GAWR - Front 4,600 lbs. 5,000 lbs. 5,000 lbs. 5,000 lbs. 5,000 lbs.
GAWR - Rear 7,800 lbs. 9,500 lbs. 9,500 lbs. 9,500 lbs. 9,500 lbs.
Wheelbase 158" 158" 190" 220" 220"
Notes:
Chalet
24V
R
4
Capacities shown are the tank manufacturer's listed water capacity (W.C.). Actual filled propane capacity is 80%
of listing due to overfilling prevention device on tank.
6
Floorplans feature a wide-body design - over 96". You should be aware that some states restrict access on
some or all state roads to 96" in body width. You should confirm the road usage laws in the states of interest to
you.
All measurements are based upon the most recent data available. See your dealer for specifications.
1
The height of each model is measured to the top of the tallest standard feature and is based on the curb weight
of a typically equipped unit. The actual height of your vehicle may vary by several inches depending on chassis o
r
equipment variations. Contact your dealer for further information.
2
The load capacity of your motor home is designated by weight, not by volume, so you cannot necessarily use all
available space when loading your motor home.
3
Capacities are based on measurements prior to tank installation. Slight capacity variations can result upon
installation.
5
Actual towing capacity is dependent on your particular loading and towing circumstances which includes the
GVWR, GAWR, and GCWR as well as adequate trailer brakes. Refer to the chassis operator's manual of your
motor home for further towing information.
