SECTION 7 –
PLUMBING
7-16
24V Waterlines • Two (2) valves beneath shower. Access through
removable panel on lower front of shower cabinet.
• Two (2) valves beneath the bed mattress. Lift mattress to
access.
Water Tank One (1) valve beneath the bed mattress. Lift mattress to
expose access hole.
Water Heater Drain plug on outside of coach, behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve
Beneath bed. Lift mattress along the front to expose access
hole.
Winterization
(Antifreeze) Valve
Located beneath bed. Lift mattress along front to expose
access hole.
26Q Waterlines Two (2) valves in galley. Remove bottom drawer under
stove.
Water Tank One (1) valve beneath the bed. Lift mattress to expose
access hole.
Water Heater Drain plug on outside of coach, behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve
Beneath galley sink. Open doors and remove panel to access
valve.
Winterization
(Antifreeze) Valve
Beneath the bed. Lift mattress to expose access hole.
31C Waterlines Three (3) valves in galley. Remove bottom drawer.
Water Tank One (1) valve beneath the bed. Lift foot of mattress to
expose access hole.
Water Heater Drain plug on outside of coach, behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve
Under galley sink. Remove bottom drawer to access.
Winterization
(Antifreeze) Valve
Beneath the bed. Lift foot of mattress to expose access hole.
31J Waterlines Two (2) valves beneath lavatory sink. Access through
removable panel.
Water Tank One (1) valve beneath the bed. Lift mattress to expose
access hole.
Water Heater Drain plug on outside of coach behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve
Beneath galley sink. Remove panel to access.
Winterization
(Antifreeze) Valve
Located beneath bed. Lift mattress to expose access hole.
To Next Page
