7-15
SECTION 7 –
PLUMBING
WATER SYSTEM DRAIN VALVE LOCATIONS
MODEL SYSTEM DRAIN VALVE LOCATIONS
31N Waterlines Three (3) valves beneath the bed. Access through removable
panel on end of bed cabinet.
Water Tank One (1) valve beneath the bed. Access through removable
panel on end of bed cabinet.
Water Heater Drain plug on outside of coach, behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve
One (1) valve under galley sink behind removable panel.
Winterization
(Antifreeze) Valve
Access through removable panel on end of bed cabinet.
