Wirquin ONE - Installing the Push Button; Fit Push Button and Rod; Screw Push Button

14 - Fit the push button into the cistern lid hole making sure the rod
is located into the push button rod locator on the internal over
flow tube.
Warning: if the rod is not located in the push button rod locator
the flushing valve will not operate.
15 - Screw the push button onto the flushing valve.
Fitting push button
Push button rod
locating hole
7
