Sage Series Minimal Appearance System Ordering and Planning
1.
Planning Stage
2.
Pre-construction / Pre-wire Stage
3.
Finishing Stage
Surface
Platform (Size & Shape)
Speaker
Final Assembly
Grille
Gypsum, 1/2” (13mm)
1/2" round 3" Platform
1/2" square 3" Platform
1/2" round 4" Platform
1/2" square 4" Platform
ICS3-BackBox
SUB1
ICS3-SPMD
3" round
3" square
4" round
4" square
Gypsum, 5/8” (16mm)
5/8" round 3" Platform
5/8" square 3" Platform
5/8" round 4" Platform
5/8" square 4" Platform
Solid Surface
Depth from 3/8” to 1-1/4”
(9.5mm 31.75mm)
Solid Surface Mounting Kit
Router Template Tool Kit
Document Conventions
This document contains general safety, installation, and operation instructions for the Wisdom
Audio Sage Series Minimal Appearance loudspeakers. It is important to read this document before
attempting to use this product. Pay particular attention to:
WARNING: Calls attention to a procedure, practice, condition, or the like that, if not correctly
performed or adhered to, could result in injury or death.
CAUTION: Calls attention to a procedure, practice, condition, or the like that, if not correctly
performed or adhered to, could result in damage to or destruction of part of or the entire product.
Note: Calls attention to information that aids in the installation or operation of the product.

Related product manuals
