Z axis vibration displacement (high
speed mode)
5.2 Module Uppermost computer
By default, the module will upload the data of Flag=0x61(vibration speed, vibration
Angle, temperature, vibration displacement and vibration frequency), totaling 28
bytes.
Packet
Data packet header
Note: 0xNN is the specific value received. The order of data return is vibration velocity XYZ,
vibration Angle XYZ, temperature, vibration displacement XYZ, vibration frequency XYZ, low byte
first, high byte last.
Flag = 0x61 Data content 26Byte indicates vibration speed, vibration Angle, temperature,
vibration displacement, and vibration frequency
X axis vibration speed is 8 bits lower
X axis vibration speed is 8 bits higher
Y-axis vibration velocity is 8 bits lower
Y-axis vibration velocity is 8 bits higher
Z-axis vibration speed is 8 bits lower
