WOERNER GFZ - Product Description; Purpose of Use; Limits of Use; Ambient Conditions

Operating manual GFZ / GFM / GEZ Page 8 of 30 B0112
3. Product description
3.1 Purpose of use
The pump unit is designed for the delivery of lube oils exclusively.
3.2 Limits of use
The application area of the pump unit’s components is restricted as follows:
Type:
GFM-F
GFM-G
GFM-N
GFM-L
GFM-L01
GFZ-B
GFZ-C
GFZ-D
GFZ-N
GFZ-L
GFZ-L01
GEZ-B
GEZ-C
Medium:
Mineral oil
Viscosity:
100 … 1350
cP
16 … 1350 cP
100 … 1350
cP
16 … 1350 cP
16 … 1520
cP
Medium
temperature:
-20 … +80 °C
-15 … +80 °C
-20 … +80 °C
-15 … +80 °C
-20 … +130
°C
Ambient
temperature:
-20 … +40 °C
-20 … +40 °C
-20 … +40 °C
-20 … +40 °C
-20 … +50
°C
Permissible
negative
pressure:
-0,3 bar
-0,3 bar
-0,3 bar
-0,3 bar
-0,3 bar
Operating
pressure
1)
:
see technical details chapter 11.5
Flow rate
1)2)
:
1)
The maximum permissable values of your pump unit can be found in chapter 11.5.
2)
The volume flow is dependend on the viscosity of the lubricant, operating pressure and
pump rotation.
Besides, the pump unit’s area of application is determined by the medium to be delivered.
Hence, when determining the area of application, you also need to refer to the technical data
sheets for the medium to be used.
3.3 Ambient conditions
Pump unit operation in an aggressive atmosphere (solvent vapours,
acids, lyes, salt water mist, etc.) may cause damage to or corrosion of
components and, thus, failure of the system and endangerment due to
leaking lubricant!
Ambient temperature range
Lower temperature limit: -20 °C
Upper temperature limit: +40 °C
Relative humidity: max. 70%
Noise level: <70 dB(A)
Physical environment
In heights as of 1.000 metres above sea level, the system should be operated after
consultation with the manufacturer only.
