Ölpumpe COB-2-20/29/40 - Einstellung Pumpendruck
Oil pump COB-2-20/29/40 - Setting pump pressure
Werkseinstellung Pumpendruck COB-2-20
factory setting pump pressure COB-2-20
ST 1 (Stufe 1/Stage 1) = 8,5 bar
ST 2 (Stufe 2/Stage 2) = 17 bar
Einstellung Pumpendruck COB-2-29/40 /
Setting pump pressure COB-2-29/40
COB-2-40 COB-2-29 COB-2-20 COB-2-15
ST1
ST2
ST1
ST2
SW 8
2 x
1 x
SW 8
¾ x
⅛ x
Pumpendruck /
Pump pressure
ST1
ST2
14 bar
25 bar
8 bar
19,5 bar
8,5 bar
17 bar
Kurzbedienungsanleitung -
Short operating instructions
