Install Ductwork
CHIMNEY WALL HOODS
CHIMNEY ISLAND HOOD
DUCTWORK
INSTALLATION
THROUGH
WALL
21" (535)
HOOD DEPTH
D
UCTWORK INSTALLATION
THROUGH ROOF
24" (610) TO 30" (762)
BOTTOM OF
HOOD TO
COUNTERTOP
30
1
/2" (775) T
O
48
1
/2" (1232)
OR
32
5
/8" (829) TO
50
7
/8" (1292)
TELESCOPING
H
OOD HEIGHT
12"
(305)
DUCTWORK INSTALLATION
THROUGH ROOF
27" (686)
HOOD DEPTH
24" (610) TO 30" (762)
BOTTOM OF
HOOD TO
COUNTERTOP
33
1
/2" (851)
T
O
47" (1194)
TELESCOPING
HOOD HEIGHT
DUCTWORK
INSTALLATION
THROUGH
EAVE—
INTERNAL
BLOWER
12"
(305)
