Planning Information
Model CTWH36 Cooktop Wall Hood
Dimensions in parentheses are in
millimeters unless otherwise specified.
4
DIMENSIONS
Overall Width of Hood 35
7
/16" (900)
Floor to Ceiling Height 8' (2.4 m) to 9' (2.7 m)
Countertop to Bottom of Hood 24" (610) to 30" (762)
Minimum Height of Hood (fully collapsed) 32
11
/16" (830)
Maximum Height of Hood (full extension) 50
7
/8" (1292)
Location of Electrical Within shaded area
See Installation Instructions shipped with unit for detailed specifications.
35
7
/16"
(900)
8' TO 9'
(2.4 m – 2.7 m)
FLOOR TO
CEILING HEIGHT
50
7
/8"
(1292)
MAXIMUM
HEIGHT OF HOOD
32
11
/16"
(830)
MINIMUM
HEIGHT OF HOOD
24" TO 30"
(610 – 762)
TO COUNTERTOP
21"
(533)
E
4"(102)
6"
(152)
*8' (2.4 m) ceilings will not allow for a 30" (762) maximum height above the countertop. Based on a 36" (914) high countertop, an 8' (2.4 m) ceiling
will allow for a maximum height above the countertop of 27
5
/ 16 " (694).
