6 | Wolf Customer Care 800.222.7820
E
FRONT VIEWSIDE VIEW
*6" (152) back from countertop cutout when internal blower is rear mounted.
NOTE: Internal blower 6"
(152) round, side, rear or bottom discharge. In-line and remote blower 10" (254) round, rear discharge.
Centerline indicates center of downdraft cutout.
21
1
/4"
(540)
21
1
/4"
(540)
8
1
/4"
(210)*
COOKTOP CUTOUT
2
11
/16" (68)
TOP VIEW
23
3
/8"
(594)
8
1
/4" (210)*
W
DOWNDRAFT
CUTOUT WIDTH
E
Downdraft
INSTALLATION WITH STANDARD INSTALLED COOKTOP
CUTOUT WIDTH W
DD30 27⁄" (699)
DD36 33⁄" (851)
DD45 39⁄" (1003)
Specifications
