To Next PageTo Next PageHow to fix Wolf Boiler radiators not warming up?
If individual radiators aren't warming up as expected with your Wolf Boiler, perform hydraulic balancing by reducing the flow rate to radiators that are already quite hot. Additionally, consider increasing the pump speed (H16).
General| Installation Type | Wall-mounted |
|---|---|
| Emissions | Low NOx |
| Type | Condensing Boiler |
| Heat Exchanger Material | Stainless Steel |
| Ignition Type | Electronic Ignition |
| Fuel Type | Natural gas |
| Water Content | Varies by model, refer to specific product data sheet |
| Weight | Varies by model, refer to specific product data sheet |
| Dimensions | Varies by model, refer to specific product data sheet |
| Operating Pressure | 30 psi (maximum) |
Guidance on storing manuals and documents safely for system users.
Key instructions for system users regarding maintenance, parts, and safety.
Guidelines for environmentally responsible disposal of old equipment and packaging materials.
Procedures for detecting and responding to gas or flue gas leaks to prevent poisoning or explosion.
Warnings and procedures for safely working with live electrical components to prevent electrocution.
Precautions against scalding from hot water and burns from hot components during operation or maintenance.
Warning about potential injuries from high water pressure within the boiler system.
Safety guidelines for working on the system and for performing regular inspections and maintenance.
Listing local regulations that must be followed for boiler installation and operation.
General regulations, rules, and guidelines applicable to the installation of heating systems.
Overview of applicable regulations for installation and operation in Germany, Austria, and Switzerland.
Information on boiler operational standards, approvals, and suitability for specific environments like garages.
Critical warnings regarding ventilation requirements and precautions for LPG operation to prevent hazards.
Advice on setting DHW temperature to prevent scalding and managing water hardness to avoid scaling.
Specifies minimum clearances for boiler installation to facilitate maintenance and testing.
Requirements for the installation room regarding temperature, air quality, and absence of flammable materials.
Conditions for wet room installation, outdoor restrictions, and system type requirements.
Instructions for mounting the boiler and identifying flue system components and dimensions.
Recommendations for installing maintenance valves and dirt traps in the heating circuit for system protection.
Guidelines for cold water and DHW connections, including pressure reducers and non-return valves.
Instructions for connecting the gas supply line, emphasizing licensed fitters and system cleanliness.
Requirement for a fire-protected gas valve and safety procedures for gas connection tightness and pressure testing.
Instructions for fitting the condensate trap, ensuring secure connections and proper hose routing for drainage.
Critical procedure for filling the trap with water before commissioning to prevent flue gas escape.
Specifies test pressures for DHW and heating water sides of the hydraulic pipework.
Guidance on using original Wolf parts for balanced flue systems and consulting technical information.
Warning about flue gas condensation and freezing at low temperatures and measures to prevent ice falling.
General information and requirements for electrical installation, including qualified contractors and regulations.
Critical warnings regarding live electrical components and the need to isolate power before work.
Instructions for opening the control unit and its back cover to access internal components.
Importance of using cable glands correctly for room-sealed operation and protecting internal components.
Diagram showing the terminal strip layout for connecting power, sensors, and control accessories.
Guidelines for connecting input signals like room thermostat, outside temperature, and DHW sensors.
Specific steps for making a permanent electrical connection, including cable routing and strain relief.
Safety precautions for changing the fuse, emphasizing power isolation before the procedure.
Instructions for connecting input E1 and external sensors, including advice on shielded cables.
Guidelines for connecting digital Wolf control accessories via eBus, including cable type and shielding.
Description of the ISM7e interface module for remote access and its operating options.
Detailed explanation of the function assigned to each key on the control unit for operation.
How to use DHW and Heating keys to adjust temperatures and select operating modes.
How to select operating modes and activate emissions test mode using control unit keys.
Explanation of display elements and how to use the info button to access readings and interpret icons.
Description of the Standby, Winter, and Summer operating modes of the boiler.
Steps to access the contractor level for parameter adjustment and navigate menus.
How to access and reset the fault history to diagnose and clear error codes.
Procedure to enable, operate, and disable the emissions test mode for combustion parameter checks.
Introduction to contractor parameters, how to access them, and a table of parameters H01-H25.
Table listing additional control parameters (H34-H55) and their factory settings.
Notes on essential parameters (H12, H40, H51) that require specific setting during commissioning.
Description of parameter H01, regulating boiler water temperature hysteresis for efficient burner operation.
Description of parameter H02, setting the minimum burner output applicable to all operating modes.
Description of parameter H03, setting the maximum burner output for DHW mode operation.
Description of parameter H04, setting the maximum burner output for heating mode operation.
Description of parameter H07, controlling the heating pump run-on time after heat demand ends.
Description of parameter H08, limiting the upper boiler water temperature in heating mode.
Description of parameter H09, defining the burner cycle block duration after shutdown.
Description of parameter H10, used for setting the eBUS address for heat sources in cascade systems.
Description of parameter H12 for setting the gas type and output, with an associated table.
Description of parameter H15, regulating the start point for cylinder heating based on hysteresis.
Description of parameter H16, setting the minimum rate for the heating circuit pump.
Description of parameter H17, setting the maximum rate for the heating circuit pump.
Description of parameter H19, setting the run-on time for the cylinder loading pump.
Description of parameter H21, setting the minimum start temperature for the boiler.
Description of parameter H23, defining the upper limit for DHW set temperature.
Description of parameter H25, selecting excess temperature differential for cylinder heating.
Description of parameter H34, enabling or disabling the eBUS feed for connected consumers.
Description of parameter H37, selecting the type of pump speed control in heating mode.
Description of parameter H38, setting the spread value for pump control when spread is enabled.
Description of parameter H39, setting the duration for reduced burner output after start.
Description of parameter H40, selecting system configuration (direct heating circuit, mixer, cascade).
Description of parameter H41, setting the pump speed for feed/heating circuit in DHW mode.
Diagrams illustrating System Configurations 02 (Mixer) and 60 (Cascade) for boiler integration.
Description of parameter H51, used to set the type of DHW heating configuration.
Description of parameter H52, enabling or disabling DHW cylinder pasteurisation to prevent bacterial growth.
Description of parameter H53, specifying the interval for activating the pasteurisation function.
Description of parameter H54, setting the heating curve to match system conditions and climate for optimal performance.
Formula and example for calculating temperature correction based on heating curve and outside temperature.
Graphs illustrating how temperature selection (-4 to +4) affects flow temperature based on outside temperature.
Description of parameter H55, maintaining DHW temperature in summer mode for increased convenience.
Description of parameter A09 for system frost protection and important cautions to prevent damage from freezing.
Procedure for leak testing hydraulic pipework and the required test pressures.
Guidelines for treating heating water according to VDI 2035 to prevent corrosion and ensure system longevity.
Table specifying limits for heating water quality parameters like hardness and conductivity.
Information on top-up water requirements, including calculations for desalinated water and total fill water limits.
Instruction to record commissioning parameters in the system log and hand it to the operator.
Step-by-step guide for filling the heating system, including flushing, venting, and checking for leaks.
Important note prohibiting the use of inhibitors and antifreeze in the heating system due to potential damage.
Instructions to check system pressure, top up if needed, and information on automatic heating circuit venting.
Steps for filling the heating circuit using the integrated filling facility and checking for component tightness.
Information on different gas types (Natural gas, LPG) and their Wobbe index values for correct setup.
Table showing gas categories and required supply pressures in mbar for various countries to ensure proper operation.
Instructions on matching the correct gas restrictor based on gas type and appliance category for optimal performance.
Step-by-step guide for changing the gas type of the boiler, including physical component changes and labelling.
How to set the gas type in the contractor level parameter H12 after physical conversion.
Procedure for performing a CO2 test after changing the gas type to ensure correct combustion parameters.
Procedure for adjusting the CO2 content at upper load during emissions testing for optimal combustion.
Procedure for adjusting the CO2 content at lower load, specifically for zero adjustment, during emissions testing.
How to adjust the maximum heating output using the control unit parameters and associated tables.
Graph illustrating the relationship between display value and heating output for different boiler models.
Procedure for checking intake air parameters, including temperature and CO2, during emissions testing.
Procedure for checking flue gas parameters (CO2, O2) at upper and lower loads, with permissible values.
Description of the high efficiency pump's operating modes (modulating, fixed speed, DHW, standby) and control.
Graph showing the residual head of the high efficiency pump relative to pump rate, indicating performance characteristics.
Troubleshooting guide for common issues with the high efficiency pump, including problems with radiator warming and room temperature.
A checklist of commissioning steps to be performed and confirmed, including system checks and parameter settings.
Section for recording test values, confirmations, and gas type information during commissioning.
Checklist items for verifying parameter settings and performing flue gas emissions tests.
Final checks including casing fit, function test, user training, and confirming overall commissioning.
Instructions on how to access the fault history from the control unit to view recent faults and provide maintenance information.
Procedure for resetting the fault history after a fault has been addressed and remedied to clear error codes.
List of required maintenance sets and part numbers, including cleaning tools and specialized devices.
Diagram illustrating the FGB spare parts included in the maintenance set for service and replacement.
Crucial safety steps to isolate the system from power and close the gas ball valve before maintenance.
Step-by-step instructions for removing the front casing to access internal components for maintenance.
Warning that some components can be very hot, requiring cooling or protective gloves during maintenance.
Instructions for fitting the pressure test connector and adapter plate to the heat exchanger for measurement.
How to read the pressure differential and determine the soiling level of the heat exchanger, comparing to limits.
Instruction on how to undo the fitting on the gas combination valve for burner maintenance.
Steps for disconnecting plug-in electrical connections like fan, gas valve, and ignition electrode.
Instructions for removing the combustion chamber cover to access and service the burner.
Procedure for cleaning the burner, including visual inspection for damage and using compressed air.
Caution against using specific cleaning agents like acids or water for cleaning the burner to prevent damage.
Instructions for cleaning the trap, including removing residue and flushing through the inspection port.
Procedure for checking the expansion vessel's pre-charge pressure if water loss is noticed, ensuring system integrity.
Steps to empty the boiler water and open the manual air vent valve before removing the heat exchanger.
Instructions for disconnecting sensors, releasing clips, and removing pipes connected to the pump and heat exchanger.
Procedure for cleaning the heat exchanger using a cleaning tool, with a caution about cleaning agents and water flushing.
Instructions for removing the condensate pan by releasing retaining clips to access the heat exchanger.
Steps for assembling the heat exchanger, including fitting condensate pans, securing clips, and positioning the flue pipe.
Instructions for refitting pipes, connecting sensors, and reconnecting plug-in connections to the pump.
Steps for refilling the boiler on the heating water side, including venting and opening valves for proper operation.
Instructions for refitting the combustion chamber cover, tightening screws, and reconnecting plug-in electrical connections.
Instructions for tightening the gas combination valve fitting, replacing seals, and checking for gas leaks.
Performing a test after assembly to check the heat exchanger soiling level and measured pressure drop values.
Actions to take if DHW output is too low, including checking filter, heat exchanger, and performing a test run.
Procedure for the test run after maintenance, including checking gas train, hydraulics, and testing combustion parameters.
Description of safety devices monitoring temperature, including high limit cut-outs, boiler, and flue gas sensors.
Description of system pressure monitoring and dry fire protection function for safe boiler operation.
Overview of different types of balanced flue systems and their connection possibilities with diagrams.
Table detailing flue gas routing options and maximum permissible lengths for various flue types.
Information on safe differential pressure limits for multiple connections of balanced flue systems.
Notes on installation examples, building regulations, and the use of original Wolf components for balanced flue systems.
General advice for balanced flue installation, including fire resistance, clearances, and combustion air source restrictions.
Warnings about flue gas condensation, ice falling, and fire resistance requirements for shafts and ceilings.
Guidance for external wall flues (C13x), including requirements for output reduction.
Examples of vertical balanced flue routing for DN 60/100 systems with various components and diagrams.
Method for calculating balanced flue length, including pipe bends and length equivalences for proper system design.
Information on minimum shaft sizes required for room-sealed operation with C93x balanced flue systems.
Instructions for connecting to C43x, B33, C53/C83x flue systems, covering different operational modes.
Information on C63x flue connections, multi-boiler systems, and requirements for shared chimneys.
Procedure for performing a tightness test on connections to adjacent appliances in cascade systems using emissions test mode.
Examples of vertical balanced flue routing for DN 60/100 systems with various components and diagrams.
Examples of horizontal balanced flue routing for DN 60/100 systems, including connections to chimneys.
Instructions for connecting to moisture-resistant flues with multiple draught chimneys (shafts), including requirements.
Supplementary installation instructions for DN80/125 balanced flues, covering flat and pitched roof installations and pipe trimming.
Examples of vertical concentric balanced flue routing for C33x systems using DN80/125, with installation notes.
Examples of horizontal concentric balanced flue routing for C13x, C83x, and B33 systems, including external wall routing.
Diagram showing concentric balanced flue installation inside a shaft for DN80/125 and C33x systems.
Diagrams illustrating connections to flues inside shafts for C93x systems.
Instructions for installing the eccentric balanced flue distributor and its connection requirements, including slope and air supply.
Supplementary installation instructions for DN80/125 balanced flues, covering roof installations, adaptor use, and bend calculations.
Design considerations for underfloor heating systems, including pipe type, connection, and system pressure drop.
Recommendation for sizing diaphragm expansion vessels for underfloor heating systems to prevent oxygen ingress and corrosion.
Table listing NTC sensor resistances at various temperatures for different sensors used in the system.
A comprehensive checklist of steps to be performed during routine service of the boiler, with sections for recording results.
General guidance on troubleshooting, safety during repairs, fault display interpretation, and fault resolution steps.
Procedure for identifying, diagnosing, and remedying faults, including acknowledging and resetting error messages.
Table detailing possible causes and remedies for fault codes 01 through 05, covering sensor errors and flame issues.
Table detailing possible causes and remedies for fault codes 06 through 24, covering temperature limiter, flue gas, and sensor faults.
Table detailing possible causes and remedies for fault codes 27 through 107, including supply issues and control unit faults.
Details of the EU Declaration of Conformity, including product identification, manufacturer, and conforming documents.
List of standards and directives that the product conforms to, ensuring compliance with EU regulations.
