Wolf KG - Intake; Discharge Hoods

21
3062049_201610
KG TopInstallationinstructions
Intake/dischargehood
Side panels
(rain gutter externally)
Top
section
Screws
Assemble the side panels and top section as shown, using
the screws supplied.
Foracongurationwithtwoorthreeintake/dischargehoods
one above the other, the upper hood overlaps the lower hood.
Overlap
Versions
KG Top 21 - 210
KG Top 270 - 380
KG Top 680KG Top 450 - 600
KG Top 850 - 1000KG Top 680 - 1000
