Wolf SO30F/S - Page 110

Wolf Pro Ventilation 110
E
6"
(152)
5"
(127)
LOCATION OF ELECTRICAL
WIDTH OF HOOD
30" (762) TO
36" (914)
TO COUNTERTOP
18" (457)
H
EIGHT
OF HOOD
27" (686)
DEPTH OF HOOD
SIDE VIEW
E
6"
(152)
5"
(127)
LOCATION OF
ELECTRICAL
WIDTH OF HOOD
30" (762) TO 36" (914)
TO COUNTERTOP
18" (457)
HEIGHT
OF HOOD
24" (610)
DEPTH OF HOOD
SIDE VIEW
27" (686) Deep Wall Hood
INSTALLATION
Wall Chimney Hood
INSTALLATION
