Planning Information
Wolf drawer microwave ovens can be installed in a
standard or flush inset application. A flush inset installa-
tion requires the microwave to be recessed into the
cabinet. Refer to the illustrations on the following pages
for minimum cabinet dimensions for your specific installa-
tion. The cabinet must be able to support 125 lbs
(57 kg).
In standard applications, the drawer microwave trim will
overlap stiles and rails and will match the overlaps of
E series ovens. Refer to the chart for overlap dimensions.
Wolf convection and standard microwave ovens can be
used freestanding or built-in with optional trim kit available
through your authorized Wolf dealer. For local dealer infor-
mation, visit the find a showroom section of our website,
wolfappliance.com.
In a freestanding application, allow 2"
(51) of airflow space
on the top, rear and both sides. Built-in opening dimen-
sions accommodate air flow space.
In built-in applications, convection and standard
microwaves with trim kit will overlap stiles and rails and
will match the overlaps of L series and E series ovens.
Refer to the chart for overlap dimensions.
Microwave Trim Overlap
DRAWER MICROWAVE 24" MODEL 30" MODELS
Top Overlap
3
/8" (10)
3
/8" (10)
Bottom Overlap
1
/8" (3)
1
/8" (3)
Side Overlap
7
/8" (22)
3
/4" (19)
27" (686) E SERIES TRIM CONVECTION STANDARD
Top Overlap
1
/4" (6)
9
/16" (14)
Bottom Overlap
3
/4" (19)
11
/16" (17)
Side Overlap
13
/16" (21)
13
/16" (21)
30" (762) L AND E SERIES TRIM CONVECTION STANDARD
Top Overlap
1
/4" (6)
7
/16" (11)
Bottom Overlap
13
/16" (21)
13
/16" (21)
Side Overlap 1
3
/16" (30) 1
3
/16" (30)
36" (914) L SERIES TRIM CONVECTION STANDARD
Top Overlap
3
/16" (5) NA
Bottom Overlap
13
/16" (21) NA
Side Overlap 1
1
/4" (32) NA
ELECTRICAL REQUIREMENTS
Electrical Requirements
MICROWAVE OVENS
Electrical Supply 120 V AC, 60 Hz
Service 15 amp dedicated circuit
Receptacle 3-prong grounding-type
Power Cord (drawer) 4' (1.2 m)
Power Cord (convection, standard) 3' (.9 m)
