Wolf SO30F/S - Page 28

Wolf Microwave Ovens 28
FRONT VIEWSIDE VIEW
24" (610) min
CABINET DEPTH
36" (914)
FLOOR TO
COUNTERTOP
23
1
/2" (597) min
OPENING DEPTH
14
3
/4" (375)
OPENING
HEIGHT
22
1
/8" (562)
OPENING WIDTH
BASE SUPPORT
E
ANTI-TIP BLOCK
*Dimension must accommodate height of anti-tip block and drawer face overlap.
NOTE: Dashed line represents profile of unit.
DIMENSION
WILL VARY*
FRONT VIEW
36" (914)
FLOOR TO
COUNTERTOP
SIDE CLEATS
24
3
/4"
(629) min
FLUSH INSET
DEPTH
1
1
/4" (32)
TOP VIEW
14
3
/4" (375)
OPENING
HEIGHT
15
3
/4"
(400)
FLUSH INSET
HEIGHT
24
3
/8" (619)
FLUSH INSET WIDTH
22
1
/8" (562)
OPENING WIDTH
E
1
1
/8" (29)
SIDE CLEATS
3
/8" (10) BOTTOM CLEAT
5
/8" (16)
TOP CLEAT
ANTI-TIP BLOCK
DIMENSION
WILL VARY*
SIDE VIEW
*Dimension must accommodate height of anti-tip block and drawer face overlap.
NOTE: Dashed line represents profile of unit.
24" (610) Drawer Microwave
STANDARD INSTALLATION
FLUSH INSET INSTALLATION
