Wolf SO30F/S - Page 29

Wolf Microwave Ovens 29
wolfappliance.com/specs
FRONT VIEW
24" (610) min
CABINET DEPTH
36" (914)
FLOOR TO
COUNTERTOP
23
1
/2" (597) min
OPENING DEPTH
14
3
/4" (375)
OPENING
HEIGHT
ANTI-TIP BLOCK
28
1
/2" (724)
OPENING WIDTH
E
BASE SUPPORT
DIMENSION
WILL VARY*
SIDE VIEW
*Dimension must accommodate height of anti-tip block and drawer face overlap.
NOTE: Dashed line represents profile of unit.
FRONT VIEW
36" (914)
FLOOR TO
COUNTERTOP
SIDE CLEATS
24
3
/4" (629) min
FLUSH INSET
DEPTH
1
1
/4" (32)
TOP VIEW
14
3
/4" (375)
OPENING
HEIGHT
15
3
/4"
(400)
FLUSH INSET
HEIGHT
30
3
/8" (772)
FLUSH INSET WIDTH
28
1
/2" (724)
OPENING WIDTH
E
1"(25)
SIDE CLEATS
3
/8"(10) BOTTOM CLEAT
5
/8"(16) TOP CLEAT
ANTI-TIP BLOCK
DIMENSION
WILL VARY*
SIDE VIEW
*Dimension must accommodate height of anti-tip block and drawer face overlap.
NOTE: Dashed line represents profile of unit.
30" (762) Drawer Microwave
STANDARD INSTALLATION
FLUSH INSET INSTALLATION
