Wolf Built-In Ovens 9
wolfappliance.com/specs
36" (914)
FLOOR TO
COUNTERTOP
E
34
1
/2" (876)
OPENING WIDTH
24
1
/16"
(611)
OPENING
HEIGHT
E
5"
(127)
4"
(102)
7
3
/4" (197)
TYPICAL*
DIMENSION WILL VARY*
24" (610) min
OPENING DEPTH
FRONT VIEWSIDE VIEW
*Dimension must accommodate height of oven trim.
NOTES: Location of electrical supply within oven opening may require additional cabinet depth.
Dashed line represents profile of unit.
36" (914) L Series Single Oven
STANDARD INSTALLATION
DIMENSION WILL VARY*
4
3
/4" (121) TYPICAL*
36" (914)
FLOOR TO
COUNTERTOP
*Dimension must accommodate height of oven trim.
NOTES: Location of electrical supply within opening may require additional cabinet depth.
D
ashed line represents profile of unit.
E
28
1
/2" (724)
OPENING WIDTH
27
3
/16"
(691)
OPENING
HEIGHT
24" (610) min
OPENING DEPTH
E
5"
(127)
4"
(102)
FRONT VIEWSIDE VIEW
30" (762) L Series and E Series Single Oven
STANDARD INSTALLATION
