Installation instructions DHW cylinders TSW-120/CSW-120
3048420_0707
4
Specification
Warning to the user
a) Do not remove adjust any component part of this unvented
water heater: Contact the installer
b) If this unvented water heater develops a fault, such as a flow
of hot water from the discharge pipe, switch the heater off and
contact the installer.
Note to the installer
Leave the manual with the householder after installation.
The safety system of the DHW cylinder TSW-120/CSW-120 is
attuned to use only in combination with Wolf boiler TGG-18, TGG-
24 and TGB-20.
a) This installation is subject to building regulation approval, notify
the Local Authority of intention to install.
b) Use only manufacturer´s recommended replacement parts.
c) Installed by: Name:
Adress:
Tel.No.:
Completion date
Warning to the
installer
Type of DHW cylinder TSW/CSW -120
Cylinder capacity litres 115
Const. DHW cyl. rating (80/60 - 10/45°C) kW-ltrs./h 29-710
Standby consumption at 60
°C kWh/24h 1.5
Performance factor N
L60
1.0
Max. supply temperature °C 60
Heating up time with 25kW min 22
Re heat time with 25kW min 15
Max. operating pressure - DHW bar 3.5
Max. operating pressure - heating water bar 12
Max. permissible DHW cylinder temperature °C 95
Max. permissible heating water temperature °C 110
P+T-valve opening temperature °C 95
P+T-valve opening pressure bar 7
Max. water supply pressure bar 16.0
Expansion valve setting bar 6.0
Expansion vessel charge pressure bar 4.0
Weight (empty) kg 75
Weight of the full cylinder kg 190
Connections Cold water R ¾”
Hot water R ¾”
DHW flow R ¾”
DHW return R ¾”
DHW circulation R ¾”
Sensor well Ø mm 14
Specification
