Components of the Visualizer
#1
#8
#10
#1 Remote Anti-theft Security Screw to fix the Remote control onto the case
(found underneath the unit as shown on page 25)
#2
#3 POWER key and Power Indication LED(see page 5)
#4 USB port to Host (computer) (see page 15)
#5 DC-output for lightbox (see page 25)
#6 Charging Dock for Touch Remote Control (see page 6)
#7 Touch Remote Release button press and lift the Touch Remote Control
#8 Connectors (on the back as shown on next page)
#9 Infrared receiver (one ir receiver on the back and on behind the glass)
#10 Sensing Head Mirror (sensitive front coated mirror)
#11 Touch Head (Panel) on the sensing head (see pages 6ff)
#12 Zoom wheel (see page 13)
#13 Working surface (see page 5)
#14 Infrared Remote Control (see pages 11 and 22)
#15 Touch Remote Control (radio frequency) (see pages 6ff)
USB port to Client (peripheral devices for external storage units) (see page 17)
3
#4
#3
#6
#5
#2
#7
#15
#9
#14
#13
#11
#12
