Parts List - Diagram 2
Parts & Diagrams
1 DC1260-1-5 Belt cover mounting plate
2 DC-RBT-01 Belt tension arm
3 DC-RBT-02 Belt tension stand off bushing
4 DC-1260BT-01-22 Belt tension pulley
5 SP-1.0 Tension spring
6 250 EYE BOLT 1/4" Eye bolt 2" long
6A 250 NUT 1/4"-20 Hex nut
7 M10x1.5x65 HHCS FT M10x1.5x65 Hex head cap screw GR 8.8
8 390 NW .390" Idx 1.00" OD nylon washer
9 M10 FW M10 FLAT WASHER ZINC
10 M10x1.5 NYLOCK M10-1.5 Nylon lock nut
11 375-16x2.50 HHCS 3/8-16x2.50 Hex head cap screw GR5 zink
12 375 FW 3/8" Flat washer zink
13 375-16 NYLOCK 3/8-16 Nylon lock nut
POS # PART # PART DESCRIPTION
