Woods CSS48 User Manual

42 Parts
MAN1280 (4/05/2019)
LIGHT KIT OPTION (P/N 611743)
REF PART QTY DESCRIPTION
1 599771 1 Main harness, 4 ft
2 1040277 1 AG enhancer module
3 611744 1 Rear harness, 31 in. (2 pcs).
5 1040275 1 LED AG combo lamp LH
6 1040276 1 LED AG combo lamp RH
7
602513RP
1 Angle, plug holder, 7 pin
8
14350
2 Nut lock 3/8 NC flange
9
6697
2 Bolt crg 3/8 NC x GR5 ZP
10 10378 8 1/4 NC x 1 HHCS, GR5
11 1041604 2 #10 NC x 1/2 self tap screw
12 W70065 8 1/4 NC whiz nut
13 35249 4 .50 dia p-clip
14 W30036 4 5/16 NC X 3/4 self tap screw
