Dealer Service 27
MAN1280 (4/05/2019)
DEALER SERVICE
DEALER SET-UP INSTRUCTIONS
Assembly of this equipment is the responsibility of the
Woods dealer. It should be delivered to the owner com-
pletely assembled, lubricated, and adjusted for normal
operating conditions.
In most cases, the Compact Super Seeder is shipped
completely assembled from the factory. The Legume
seed boxes, front disc roller, front studded roller, culti-
packer, and tow kit are options that can be added to the
Compact Super Seeder at a later time if desired.
Optional Accessories
Front Spike Roller (For illustration, see page 38)
1. Place seeder on level surface with jack stands
under 2 x 3 front frame tube.
2. Stop engine and set parking brake.
3. Place hoist strap around disc gang axle.
4. Remove 3/4” U-bolts and nuts connecting 2 x 3
tube to disc gang.
5. Using hoist strap, carefully remove disc gangs from
underneath seeder.
■ Notched disc blades are sharp. Wear gloves
and tight fitting clothing.
6. If 48” seeder, remove 2 x 3 tube and replace with
disc 2 x 3 tube. Install 5/8” bolt, nut 5/8” bent pin
and hair pin clip. If 60” seeder, use existing 2 x 3
tube.
7. Carefully position front rollers under frame and
attach to 2 x 3 tube using 3/4” U-bolts and nuts.
Allow mounts to locate naturally to 2 x 3 tube when
tightening hardware without allowing them to twist
or cock. Position rollers with 1/2” gap between
middle end shafts.
Front Disc (for illustration, see page 39)
1. Place seeder on level surface.
2. Stop engine and set parking brake.
3. Place hoist strap around front roller.
4. Remove 3/4” U-bolts and nuts connecting 2 x 3
tube to roller.
5. Using hoist strap, carefully remove rollers from
underneath seeder.
6. If 48” seeder, remove 2 x 3 tube and replace with
roller 2 x 3 tube. Install 5/8” bolt, nut, 5/8” bent pin
and hair pin clip. If 60” seeder, use existing 2 x 3
tube.
7. Carefully position disc under frame and attach to 2
x 3 tube using 3/4” U-bolts and nuts. Allow mounts
to locate naturally to 2 x 3 tube when tightening
hardware without allowing them to twist or cock.
Position disc gangs with 1-1/2” gap between
middle axle shafts.
■ Notched disc blades are sharp. Wear gloves
and tight fitting clothing.
Legume Seed Box (for illustration, see page 36)
1. Place seeder on level surface.
2. Stop engine and set parking brake.
3. Open Cool Season seed box shield.
4. Remove SMV sign from Cool Season seed box
saving 1/4” hardware.
5. Install Legume seed box on seeder frame and
Primary box using 3/8” hardware and 5/16”
hardware respectively.
6. Remove short agitator chain from Primary seed
box.
7. Install Legume drive chain around Cool Season
seed cup sprocket, around Cool Season seed box
agitator sprocket, underneath Legume idler
sprocket and around Legume seed cup sprocket.
8. Install SMV sign on Legume box with 1/4”
hardware.
9. Install Legume shield to Cool Season box shield
with 1/4” hardware.
10. Install seed cup PVC tubes on seed cups and
insert into legume transition tray.
Cultipacker (for illustration, see page 40)
1. Place seeder on level surface.
2. Stop engine and set parking brake.
3. Match cultipacker mounts with holes in frame and
install 3/4” x 1-1/2” bolt, 3/4” washers (48” CSS
only) and 3/4” flanged lock nuts. Place washer
between frame and cultipacker mounts.
4. Install spring stops on frame.
5. Install spring rods and springs on cultipacker arm
and in holes of spring stops.
6. Adjust jam nuts on spring rods to tighten spring to
desired setting.
