Woods CSS48 - Page 45

Parts 45
MAN1280 (4/05/2019)
SPIKE DRIVE ROLLER MUD SCRAPERS OPTION
(P/N 61564548 FOR CSS48)
(P/N 61564560 FOR CSS60)
REF PART DESCRIPTION QTY
1 615191 Mount, scraper, rear roller CSS LH 1
2 615192 Mount, scraper, rear roller CSS RH 1
3 51248 Bolt crg 5/16 x 3/4 GR5 ZP 2
4 1046048 Nut, 5/16 round push 2
5 14139 Nut lock 5/16 NC flng HD ZP 2
6 61519060 Scraper, rear roller CSS60 1
6 61519048 Scraper, rear roller CSS48 1
