Woods FZ23B - Page 43

Parts 43
MAN0875 (2/8/2011)
BRAKE ASSEMBLY PARTS LIST (CONTINUED)
HEADLIGHT KIT (OPTIONAL)
NOTES: Headlight power outlets are located near the
steering pivot blocks.
REF PART QTY DESCRIPTION
23 2985 * 1 1/4-28 Tapered thread grease fitting
24 3145 * 6 3/32 x 1/2 Cotter pin
25 70024 3 Clevis pin
26 3231 * 1 3/8 NC x 2 HHCS - GR5
27 12169 * 7 3/8 NC x 1-1/4 HHCS - GR5
28 6698 * 8 3/8 NC Hex lock nut
29 835 * 1 3/8 NC Hex nut
30 35709 * 2 10-24 x 3/4 Pan head machine screw
31 35710 * 2 10-24 Nylok nut
REF PART QTY DESCRIPTION
32 4115 * 1 3/16 x 1-1/8 Spring pin
33 6096 * 2 5/16 NC x 3/4 HHCS - GR5
34 6778 * 2 5/16 NC Hex lock nut
35 75487 2 Wheel motor
36 639 * 8 1/2 NC x 2-1/2 HHCS - GR5
37 62149 * 1 5/16 NC Jam nut
38 74043 1 5/16 NC x 2-1/2 Hex turnbuckle
39 74044 1 Lower link rod
40 4378 * 1 5/16 Flat washer
* Standard Hardware - Obtain Locally
REF PART QTY DESCRIPTION
73938 Headlight kit
1 73937 1 Light bracket - left
2 73936 1 Light bracket - right
3 73935 2 Rect. work light with switch
4 07516000 4 Button bumper
5 6096 * 4 5/16 NC x 3/4 HHCS
6 2472 * 4 5/16 Lock washer
REF PART QTY DESCRIPTION
7 4378 * 4 5/16 Flat washer
8 5288 * 2 1/4 NC Hex nut
9 1985 * 2 1/4 Lock washer
10 -------- * 8 Plastic tie
* Standard hardware, obtain locally
