4 Introduction
MAN0988 (11/5/2012)
SPECIFICATIONS
GENERAL INFORMATION
The purpose of this manual is to assist you in operating
and maintaining your Precision Super Seeder. Read it
carefully. It furnishes information and instructions that
will help you achieve years of dependable perfor-
mance. These instructions have been compiled from
extensive field experience and engineering data. Some
information may be general in nature due to unknown
and varying operating conditions. However, through
experience and these instructions, you should be able
to develop procedures suitable to your particular situa-
tion.
The illustrations and data used in this manual were cur-
rent at the time of printing but, due to possible inline
production changes, your machine may vary slightly in
detail. We reserve the right to redesign and change the
machines as may be necessary without notification.
Precision Super Seeder should never be oper-
ated with any safety shielding removed.
Throughout this manual, references are made to right
and left direction. These are determined by standing
behind the equipment facing the direction of forward
travel.
PSS48 PSS60 PSS72 PSS84
Working Width 49.25" 60" 72" 84"
Overall Width (Maximum Configuration) 61.25" 72" 84" 96"
Spike Roller Pins 1/2" x 1-3/4" 1/2" x 1-3/4" 1/2" x 1-3/4" 1/2" x 1-3/4"
No. of Roller Pins (Front and Rear) 256 320 384 448
Front roller Positions 0-20°
(7 positions)
0-20°
(8 positions)
0-19°
(9 positions)
0-17°
(9 positions)
Front Disc Angle 0°,8°,12°,17°,23° 0°,6°,10°,14°,18° 0°,5°,8°,11°,15° 0°,4°,6°,10°,13°
Roller Diameter (Front and Rear) 8.6" 8.6" 8.6" 8.6"
Disc Diameter (Number) 16" notched (8) 16" notched (8) 18" notched (10) 18" notched (12)
Disc Spacing 7.5" 7.5" 7.5" 7.5"
Hitch Cat I, II Cat I, II Cat I, II Cat I, II
Quick Hitch compatible Y Y Y Y
Tractor HP Requirement 25-45 hp 30-65 hp 35-85 hp 40-125 hp
Weight - Studded Roller, Primary Box 779 lbs. 861 lbs. 1132 lbs. 1249 lbs.
Weight - Hunting Editions (Disc, Primary Box,
Legume Box, Cast Iron Cultipacker)
1079 lbs. 1208 lbs. 1550 lbs. 1747 lbs
Weight - All Boxes with Seed 1668 lbs. 1922 lbs. 2389 lbs. 2711 lbs.
Weight - Hunting Editions (Disc, Primary Box,
Legume Box, Nylon Cultipacker)
968 lbs. 1064 lbs. 1369 lbs. 1535 lbs.
Primary Seedbox Capacity (bu) 4 5 6 7
Legume Seedbox Capacity (bu) 1 1.25 1.5 1.75
Native Seedbox Capacity (bu) 5 6.25 7.5 8.75
Seedcups/Picker wheels 7 8 10 12
Cultipacker Diameter (Number) 9" (22) 9" (26) 9" (32) 9" (37)
Calibration Tray Standard Standard Standard Standard
Seed Distribution Method Broadcast drop
with wind deflec-
tor tray
Broadcast drop
with wind deflec-
tor tray
Broadcast drop
with wind deflec-
tor tray
Broadcast drop
with wind
deflector tray
WARNING
(Rev. 4/24/2018)
