Woodward ProTech-GII 8237-1599 User Manual (English)

Questions and Answers:

A
Ashley DoyleAug 12, 2025
How to troubleshoot power supply input alarm on Woodward ProTech-GII 8237-1599?
- B
  Brent RosalesAug 12, 2025
  If the Woodward Security Sensors power supply inputs aren't working and a power supply input alarm is present, check the wiring and terminal block connections to ensure they are secure. Verify that the breaker or fuse for the power source is not open. Confirm that you have at least two power supplies connected. On the front panel, press the VIEW button under the ALARM LED and check for Power Supply 1 or 2 Fault. Check the input voltage level to ensure it's within the acceptable range according to the electrical specifications, and verify the power supply has the appropriate rating to power the ProTech-GII.
C
caseyjenniferAug 16, 2025
What to do if trip relays are not working on Woodward ProTech-GII 8237-1599?
- R
  Rachel JohnsonAug 16, 2025
  If the trip relays on your Woodward Security Sensors are not working, check the wiring and terminal block connections. Using the Programming and Configuration Tool or front panel, verify that the trip configuration is set correctly, considering that energize-to-trip versus de-energize-to-trip inverts the polarity on the relays. Check the power supplies that provide voltage to the relay output. If you are using the 24 V EXT available from the ProTech-GII, measure the voltage between terminals 80 and 81 to ensure it is 24 V ±10%. If it is not, remove the wiring from the 24 V EXT to unload the output and measure again to verify the voltage is not being overloaded.
M
Mary KellyAug 19, 2025
How to fix Woodward ProTech-GII 8237-1599 Security Sensors speed input not working?
- J
  Janet VillanuevaAug 19, 2025
  If the speed input on your Woodward Security Sensors is not working, verify the wiring and terminal block connections. On the front panel, check the Speed Input Configure Menu to ensure all configuration options are correctly selected. Verify there are no alarms or faults indicating a setup problem, such as open wire trip, speed lost, or speed fail. Ensure the input signal levels are within the electrical specifications and check the shield connections. If using an active probe, disconnect it and measure the voltage from terminals 69 to 71; it should be 24 V ±10%. Reattach the probe and measure again to verify it is not overloading the voltage provided by the ProTech-GII.
J
Joseph NashAug 25, 2025
Why is the alarm relay output not working on Woodward Security Sensors?
- H
  Heather DavisAug 25, 2025
  If the alarm relay output on your Woodward Security Sensors is not working, check the wiring and terminal block connections. Inspect the power supplies that provide voltage to the relay output. If you're using the 24 V EXT available from the ProTech-GII, measure the voltage between terminals 80 and 81 to verify it's 24 V ±10%. If it is not, remove the wiring from the 24 V EXT to unload the output and measure again to verify the voltage is not being overloaded.
A
Alejandro ThompsonAug 27, 2025
What causes dedicated discrete input malfunction in Woodward ProTech-GII 8237-1599 Security Sensors?
- T
  Travis JohnsonAug 27, 2025
  If a dedicated discrete input (Start, Reset, or Speed Fail Override) on your Woodward Security Sensors is not working, verify the wiring and terminal block connections. On the front panel, check the Dedicated Discrete Inputs Monitor Menu and ensure the logic state is correct. Check the signal level to confirm it's within the acceptable range per the electrical specifications. Measure the voltage from terminal 1 to terminal 81; it should be 23 V ±2 V. If it is out of range, return the unit to Woodward.
W
wsantosAug 30, 2025
How to troubleshoot analog output issues on Woodward Security Sensors?
- M
  martinwhitneyAug 31, 2025
  If the analog output on your Woodward Security Sensors is not working, verify the wiring and terminal block connections. On the front panel, check the Monitor Analog Output Menu and ensure that the analog output is reading an expected output value. Measure the current from terminal 64 and verify it corresponds to the previous step. Verify the load on the analog output is within the electrical specifications. Using the PCT or front panel, verify the scaling is correct.
A
Anthony MclaughlinSep 3, 2025
What to check if MODBUS is not functioning on Woodward ProTech-GII 8237-1599?
- F
  Frank ReidSep 3, 2025
  If MODBUS is not working on your Woodward Security Sensors, verify the wiring and terminal block connections. Specifically, ensure the HI and LO wires are terminated to the correct terminals for RS-485, and likewise for TXD and RXD for RS-232. Also, verify the termination jumpers are installed for RS-485 mode. Using the PCT or front panel, verify the correct settings are selected.
M
Michael MontgomerySep 7, 2025
How do I fix a Programming and Configuration Tool issue with Woodward ProTech-GII 8237-1599 Security Sensors?
- B
  Brent BakerSep 7, 2025
  If the Programming and Configuration Tool is not working with your Woodward Security Sensors, verify that the cable plugged into the DB9 port is not a crossover cable; a straight-through cable is required. Check that power is applied to the ProTechTPS module and that the service tool is connected. Verify the correct COM port is selected when establishing communications and that Auto Detection BAUD rate is selected.
