11
Fig. 12. Off On No Demand.
Fig. 11. Basic control.
Control box
connector block
Double outlet
frost thermostat
Mains
supply
230/
240V
50Hz
Time clock/
programmer
Central
heating
Room
thermostat
Circulating pump
N
N
L
E
3
Hot water
5 Amp
Control box
connector block
Double outlet
frost thermostat
Mains
supply
230/
240V
50Hz
Time clock/
programmer
Central
heating
Room
thermostat
Cylinder
thermostat
Circulating pump
N
N
L
C
NONC
E
3
Hot water
5 Amp
