Hot Water:
1. Press select button to choose
off = constantly OFF
timed = up to 3 ON and 3 OFF time periods as
programmed
once = ON from first ON until third OFF time
period as programmed
The default ON/OFF periods pre-pro
grammed for hot water pre-heat are
shown in the table opposite.
on = constantly ON
2. Press “advance” button:
ON = hot water pre-heat light on
(hot water pre-heat stays on until
next off time period)
OFF = hot water pre-heat light off
(hot water pre-heat stays off until
next on time period)
NOTE: Advance has no effect with the constantly
on or off selected on the receiver.
DT10RF RECEIVER
OPERATING CONTROLS
OPERATING & INSTALLATION
INSTRUCTIONS
DT10RF PROGRAMMER
INSTRUCTION MANUAL
8 716 115 493a (02.2009)
14
