Worcester GREENSTAR 30CDi System User Manual

CONTROLS
WORCESTER BOSCH GREENSTAR 30CDi System
6 720 612 454a (05/10)
12
A
D
F
L
C
B
G
H
M
E
I
K
J
6 720 611 928-01.1O
minmin
5
A - MASTER SWITCH FOR ON/OFF
B - MAINS ON/OFF INDICATOR +
FAULT DIAGNOSTIC LIGHT
C - CENTRAL HEATING TEMPERA-
TURE CONTROL
D - BURNER ON INDICATOR LIGHT
(GREEN)
E - FAULT RESET BUTTON
F - SERVICE BUTTON
G - DOMESTIC HOT WATER TEMPE-
RATURE CONTROL (ONLY IN
CONJUNCTION WITH OPTIONAL
DIVERTER VALVE)
H - ECO BUTTON (ONLY IN CON-
JUNCTION WITH OPTIONAL
DIVERTER VALVE)
I - SYSTEM PRESSURE GAUGE
J - POSITION FOR OPTIONAL
PROGRAMMER
K - DISPLAY
L - CENTRAL HEATING BOOST
BUTTON
M - HOLIDAY BUTTON (ONLY IN
CONJUNCTION WITH OPTIONAL
DIVERTER VALVE)
CONTROLS
USING YOUR
APPLIANCE

Worcester GREENSTAR 30CDi System Specifications

General

Model	GREENSTAR 30CDi System
Category	Boiler
Output	30kW
Boiler Type	System
Efficiency Rating	A
Fuel Type	Gas
Operating Pressure	3 bar
Warranty	5 years
