Appliance information
Greenstar i System
ErP
- 6 720 806 945 (2015/07)
7
3 Appliance information
3.1 Appliance
Fig. 1 Standard package
[1] Wall hung gas-fired condensing system appliance for central
heating and domestic hot water.
[2] Wall mounting frame.
[2.1] Condensate pipe routing.
[2.2] CH Flow.
[2.3] Gas.
[2.4] CH Return.
[2.5] Pressure Relief Valve outlet.
[3] Hardware literature pack:
• Installation, Commissioning and Servicing Instructions
•User guide
• Wall mounting template
• Sealing Pack
[4] ErP label.
[5] Facia panel.
[6] Bottom panel.
6720806945-01.1Wo
1
3
5
6
2
2.3
2.1
2.5
2.4
2.2
4
3
3
0
m
m
7
0
0m
m
*
40
0
mm
*
7
1
0
mm to t
o
p of c
a
s
e
fr
o
nt
