User Manual/Manual de Uso PA 4100
TECHNICAL SPECIFICATIONS
Output Power (RMS) 4 x 250 W
Audio Inputs 4 MIC / LINE, 2 AUX level
600 Ω / 2.8mV
LINE (Impedance/Sensitivity)
MIC (Impedance/Sensitivity)
3k Ω / 316 mV
AUX (Impedance/Sensitivity)
50k Ω / 316 mV
OUTPUTS
INPUTS
High Impedance Line
Low Impedance
25 / 70 / 100 V
4 / 8 Ω
Frequency Response 50 Hz ‐ 17 kHz +/‐ 3dB
EQ Control (Bass) +/- 10 dB / 22 Hz ‐ 180 Hz /Centre Frequency 50 Hz
EQ Control (Treble) +/- 10 dB / 3k Hz ‐ 20 kHz /Centr Frequency 12 kHze
S/N ratio > 90 dB (Line), > 80 dB (MIC)
Total harmonic distortion Less than 1% at 1 kHz, rated power
Chime Two tone chime (‘Ding‐dong’ pre-announcement chime)
Priority Tel./Emer. ‐ MIC 1
Main Supply AC power 115 /230 V - 50/60 Hz
Consumption 1800 W
Dimensions 483 x 132 x 410 mm ( W x H x D)
Weight 25.2 kg.
483 mm
410 mm
88 mm
DIMENSIONS
EN
