5. BEFORE STARTING THE EQUIPMENT
Hazard!
Charge the battery only with the charging unit
supplied.
NOTE Make sure your battery is fully charged. The
tool comes equipped with charger and built-in battery
so there is no need to ever remove or replace the
battery. The 3.6V Lithium-ion battery is equipped to
provide up to 1100 shots on a single charge.
5.1 Charging Procedure
1. Plug the charger into the back of the tool (Fig 9).
2. Plug the charger into the wall outlet.
3. Charging may take up to 2 hours.
STAPLE LENGTH GUIDELINES
1/4" 6mm
5/16" 8mm
3/8" 10mm
1/2" 12mm
9/16"14mm
Can be used on window screens & shades, light draperies, shelf papers, closet lining, etc.
Can be used on light upholstery and other relatively thin materials.
LEG LENGTH
5/8”(15mm)
RECOMMENDED USES
Picture framing, small molding
BRAD AND PIN LENGTH GUIDELINES
Low Voltage Cabling (for cables less than 6mm Dia and 50V Max)
STAPLER: APPLICATIONS
• Upholstering
• Decor
• Wire
CANVAS/SCREEN APPLICATIONS
• Holiday Light
• Antenna wiring
• Telephone Wiring
• Alarm system wire
• Cable TV
• Audio System
• Stretching Canvas-Art
• Mesh/Screening
• Framing
• Framing Fabric
• Needlepoint
Can be used where thickness of material being stapled is substantial, for example,
foam insulation board or heavy folded draperies(about 1/4’’(6.3mm) to (9.5mm) thick).
(For cable 6mm max wire dia 50 V max voltage)
Can be used on insulation, weather stripping, wire mesh, carpet pads, canvas and other
materials of moderate strength where material thickness is up to about 3/16’’ maximum.
GB
5.2 Charge Indicator Light Status
a. While the charger is unplugged:
Green = good charge
Red flash = low battery
Green flash = good battery, tool in power saving
mode.
Red & Green alternately flash = Some errors have
happened during you firing the tool,need to check
the staples and restart the tool to continue to
operate.
b. While the charger is plugged in:
Red flash = charging
Green = full charged
Yellow flash = The tool battery will not be
charged,as battery temperature may be outside of
operating range,cool down the battery temperature
to between 40°F(0°C) and 104°F(40°C).
Tool will not fire staples while charger is plugged in.
Disconnect the charger from the tool when
charging is complete.
