High Pressure Washer
1800 505 8311 acs@americancustomerservice.com
Operation Rules - Preparation
7
4.2.3 The pump of the cleaner has the function of automatic unloading.
When the spray gun trigger closes, the unload valve opens, and the
water ows back to the suction side of the pump, so the cleaner has
the feature of low consumption of water and electricity.
4.2.4 Use the NO.32 machine oil and the high-temperature lubricating oil in
the pump.
5. Operating rules
5.1 Preparation
5.1.1 If on unpacking the unit, you discover damage has been caused
during transportation, please contact your dealer.
5.1.2 Check to make sure that the packing list and the information paper are
correct, then conserve it.
5.1.3 Insert the big handle into the
unit body, by the 3 buckles.
5.1.4 Revolve the inlet male connector
into the inlet hose, and tighten.
Figure 1
Figure 2
