WARNING: Ensure the engine is switched o while undertaking
this task.
1. Turn the fuel tap/ lever (26) to the ‘o’ position (Fig AG).
3. The fuel tank inlet lter (27) is located directly under the fuel tank cap
(2) and protects impurities entering the fuel tank (1) during refuelling.
Remove the fuel tank cap (2) by turning in an anti-clockwise direction
(Fig AH).
4. Remove the fuel tank inlet lter (27) (Fig AI) and wash thoroughly
in petrol.
5. Re-assemble by putting the fuel tank inlet lter (27) back, and then
securing the fuel tank cap (2) in a clockwise direction until rmly secured
It is very important to maintain an air lter (21) in proper condition. Damage to
the generator may arise if the lter has:
• Improperly been serviced.
• Dirt and other foreign elements adhering to the lter due to improper
installation and engine wear.
It is recommended the air lter (21) is cleaned every 50 hours (every 10 hours
under dusty conditions).
ALWAYS keep the lter clean at all times.
WARNING: Ensure the engine is switched o while undertaking this task.
1. Remove the air lter cover (20) on the side of the generator using the
supplied 10mm tube spanner (30) by removing (unscrewing) the two
screws on the face of the cover, in an anti-clockwise direction (Fig AE).
2. Remove the air lter (21) (Fig AF).
3. Wash the air lter (21) in hot soapy water and allow to dry.
4. Lubricate the air lter (21) using engine oil (SAE 10W-30).
5. Thoroughly squeeze the air lter (21) removing any excess oil.
6. Replace the air lter (21).
7. Secure the air lter cover (20) back on to the side panel of the air lter
housing using the supplied 10mm Tube Spanner (30) by screwing back in
the two screws in a clockwise direction until secure.
IMPORTANT. Never run the engine without the air lter element in place.
CAUTION: Never use fuel or low burning paint solvents to clean the air lter
(21). A re or explosion could result.
CAUTION: Ensure the air lter (21) is dry before re tting.
Replacement air lters
are available from www.
extrabattery.com.au or by
calling Customer Service
on 1800 909 909.
Maintenance Maintenance
AF.AE.
AI.AH.
AG.
ON
OFF
Air Filter Fuel Tank Inlet Filter
