6
CUSTOMER SERVICE
UK: 0800 / 328 6020
Info@globaltronicssupport.com
GT-MM-10, 09/13, E46106
Ireland: 00800 / 4467 5888
Detecting hidden objects
CAUTION
In order to avoid personal injury or property damage, please note the
following:
– Beams/girders are built into brickwork at regular distances. Determine
the distance of the beams/girders prior to working on brickwork.
– Irregularities in the distances indicate e.g. electric cables or water lines.
– Measurement errors can occur based on the surface condition.
– If you detect something, always check whether it is an electric cable.
– If the lightning symbol appears in the display, it is a conductive electric
cable.
– Static charges can extend the coverage area of an electric cable by up to
30 cm.
– Do not carry out any work on brickwork in this area.
– Work is only permitted in the area of electric cables, once the power
supply is disconnected at the consumer unit. If in doubt seek the advice
of an electrician.
– The detected object can be wider or narrower than shown in the display,
depending on the depth.
– Always mark the start and end of the object. The middle between both
marks is then the middle of object.
The following objects (materials) can be detected with the device:
Wood/beams (STUD), maximum detection depth 19mm
Metal (METAL), maximum detection depth 30mm
With the (DEEP) setting, particularly deeply positioned beams/wood and metal
parts can be detected (max. detection depth 38 mm)
Electric cables (AC), maximum detection depth 50mm
Select mode
Press the MODE button to select the required mode
STUD > METAL > DEEP >AC.
Calibrating device
The device must be calibrated to the characteristics of the body (wall, floor,
ceiling):
prior to the start of each search
regularly during a search process (after every 60 seconds)
Multi Sensor UK WORKZONE E46106.book Seite 6 Montag, 22. April 2013 1:20 13
