Workzone Q1W1524 User Manual

8
Technical specifications
Patio and wall cleaner Q1W1524
Max. permissible pressure P max. 15 MPa
Inlet flow temperature t in max. 60°C
The patio and wall cleaner is designed for pressure washers working at a nominal
pressure (p) of 90-150bar .
Assembly and Parts List
Fig.2
1. Extension tubes
2. Patio cleaner
3. Adaptor H
4. Adaptor E
5. 2 spare nozzles for patio cleaner
Assembling
• Connection of extension tube (1) and
cleaners (2):
Push the extension tube onto the pivoting
connector of cleaner(2), then rotate to
the fixing position.
Fig.3
