World Cat
5-10
GENERATOR
The Mase™ generator is installed under the port seatbox, and can be accessed using the hatches
located on the inboard and aft walls, or the seatbox can be removed if necessary. For rigging information,
review pages 19 and 20 of this manual. Prior to using the generator, review the manual provided by
Mase™ which is included in your “Owner’s Portfolio”. Follow these startup guidelines before each use of
the generator:
1. Verify that the seacock located in the port aft bilge compartment is open.
2. Verify that the “Port Start” battery switch is “ON”.
3. Turn off the “Ship Power” breaker and all accessory breakers located on the AC Panel
4. Press the “ON” button on the generator control panel, located on the aft cabin wall, and
wait for the unit to perform its self-test. If the LCD screen displays “00000” then proceed
to step 5. If an error message is displayed on the LCD screen, do not attempt to start the
unit. Contact your dealer and schedule a maintenance check.
5. Use the start button on the control panel to crank the generator.
6. Once the generator is running, engage the “SHIP POWER” circuit breaker and verify that
the “REVERSE POLARITY” indicator is not lit. If it is not lit proceed to step 7, however,
if the red LED indicator is lit, immediately turn “OFF” the “SHIP POWER” breaker and
shut down the generator. Notify your dealer regarding the issue and have a trained electri-
cian inspect your boat to determine if any damage has been sustained by the electrical sys-
tem.
7. You may now engage the AC accessory breakers.
Routine maintenance should be performed on this unit using the guidelines established by Mase™
North America. Failure to comply with these guidelines will result in loss of warranty coverage and creates
the potential for property damage or personal injury.
CLIMATE CONTROL UNIT
The convenience package also includes a heating/air conditioning unit mounted behind the port deck-
wing. It can be accessed using the hatch forward of the port seatbox or by removing the bulkhead located
aft of the cabin sink. The filter assembly, 4” vent, and control panel are located in this bulkhead. Follow
these startup guidelines before each use of the unit:
1. Verify that the seacock located in the starboard aft bilge compartment is open.
2. Using the guidelines provided, energize the AC panel using the generator of shore power
connection and engage the corresponding circuit breaker.
3. Turn the climate control unit on and select the operating mode and desired temperature
using the selection tools. This will engage the raw water pump located in the starboard aft
rigging compartment.
4. Once the unit is running, inspect for water flow through the system by checking the thru-
hull located on the port sponson (see Thru-Hull drawing page 23). If water is not flowing,
shut down the unit immediately to prevent damage. Then have your dealer inspect the sys-
tem.
Similar to a residential system, the filter units must be replaced at regular intervals to ensure proper
operation. Use the manual provided in your “Owner’s Packet” to obtain requirements for service, and to
get recommendations on usage.
