3 English
Unpacking / Standard Accessories
1. Remove all packing material. Recycling is recommended.
2. Carefully remove the hand dryer from the shipping carton, using care not to drop the appliance.
3. Inspect carefully for any damage that may have occurred during transit. Check for any loose,
missing or damaged parts. If the hand dryer is damaged or missing parts, promptly inform the
dealer where you purchased it.
Standard items included with the hand dryer are:
User Manual
Wall Mounting Bracket with
mounting anchors
HEPA Filter Cartridge with Odor
Neutralizing Tablet
Cleaning Brush
Manual
Installation Template
Installation
CAUTION Improper mounting could result in personal injury or property damage.
1. Use the mounting template provided to mark the locations for the (4) wall
mounting anchors to attach the wall mounting bracket to the wall.
2. It is recommended that at least 1 of the 4 mounting anchors for the unit be
fastened into a wall stud or support.
3. To use the hollow wall anchors included with the wall mounting kit, pre-drill the
wall in the marked locations using a 5/16” (8mm) drill, insert the plastic anchors
and tap flush to the wall.
4. Complete the attachment of the wall mounting bracket to the wall with the (4)
mounting anchors using a No. 25 torx screwdriver.
5. Hang the hand dryer on the bracket. Remove water collection tray from bottom
of dryer, and complete the attachment of the dryer with the 4th anchor.
6. Connect power supply wiring to terminal block and secure Power Supply Cover
7. Replace the water collection tray.
Power Supply
Cover Kit
